Evaluating the efficacy of a novel periosteal flap in cochlear implantation: a retrospective surgical audit at a tertiary teaching hospital

Abstract

Background

This research aimed to critically evaluate the safety and reliability of a new periosteal flap technique in cochlear implantation through a comprehensive surgical audit. A surgical audit was conducted on a cohort of 39 patients who underwent cochlear implantation at a tertiary teaching hospital from July 2020 to September 2021. The novel periosteal flap technique was utilized in all cases. Patients were followed up for a period ranging from 2 to 12 months. For comparison, outcomes were assessed by comparing 51 children who had undergone cochlear implant surgery between July 2017 and June 2019, utilizing the anteriorly based palva flap. A scoring system was employed to evaluate various aspects, including ease of surgical exposure, flap maneuverability, ease of closure after device fixation, immediate postoperative complications (up to 24 h), and delayed complications (up to 30 days). Scores ranging from 1 (fair assessment) to 4 (excellent assessment) were assigned, with a maximum score of 18 indicating optimal outcomes.

Results

The comparison between the two groups revealed a reduced incidence of emissary vein injury and easier wound closure after device fixation in the novel periosteal flap group (p = 0.000). The mean total scores were significantly higher in the novel periosteal flap group, indicating superior outcomes. Only 2 out of 39 children with the novel flap experienced minor skin color changes during the initial postoperative period, which resolved within approximately 7 days. Major complications such as wound infection, hematoma, or device migration were not observed with the new periosteal flap. Furthermore, no flap revisions were required.

Conclusions

The novel and innovative periosteal flap demonstrated both safety and reliability in cochlear implantation procedures. This well-vascularized and robust flap offered effective device coverage with minimal flap-related complications. Its time-saving nature further enhances its clinical utility. Additional validation from different medical centers would further corroborate the advantages of this easily implemented periosteal flap technique.

Level of evidence

Level 3.

Background

Cochlear implant surgery has been a well-established treatment for individuals with profound sensorineural hearing loss for over four decades. During this time, several modifications to the surgical technique, including variations in the incision, periosteal flap type, and cochlear approach, have been proposed by various surgeons to improve outcomes [1,2,3]. The use of a post-aural incision in an S-shaped fashion along with an anterior-based flap has been widely adopted in cochlear implantation procedures [2, 3].

Despite these innovations aimed at enhancing the safety of cochlear implantation, complications related to the periosteal flap persist in the postoperative period. Surgeons have continued to explore novel flap techniques to improve surgical safety and provide optimal device coverage. For instance, Balkany et al. introduced the periosteal pocket technique, which secures the receiver stimulator unit without bone drilling [4]. Orhan et al. proposed a tailed palva flap within the subperiosteal pocket technique, aiming to enhance receiver stimulator unit stabilization and prevent migration [5]. Fouad et al. reported successful outcomes with a newly designed anteriorly based periosteal flap in 26 patients [6]. Additionally, Kirtane et al. utilized a posterosuperior-based periosteal flap in their cochlear implantation series [7].

Despite various techniques, the incidence of major flap-related complications ranges from 1.08 to 8.2% [8, 9]. Flap-related complications need treatment in forms of local wound care or debridement and flap cover and in severe cases. Explantation may be required. The study by W. Gawecki et al. reported revision surgery with explanation in 47.4% of the cases of major flap-related complications which is high [10]. In line with this ongoing pursuit for improved surgical techniques and avoid such complications, the present study aims to conduct a surgical audit of patients who underwent cochlear implantation utilizing a new periosteal flap technique introduced by our center [1]. The evaluation of outcomes associated with this novel flap approach is critical for advancing the safety and efficacy of cochlear implantation procedures.

Methods

Surgical technique

All procedures were done by a single surgeon under general anesthesia. Patients were positioned supine, with the head turned away from the operation site. A postauricular incision, approximately 3 cm long and 1.5 cm behind the retroauricular sulcus, extended from just below the hairline to the mastoid tip. Skin flaps were elevated subcutaneously to fully expose the periosteum. A curvilinear periosteal incision, starting posteriorly then curving anteriorly, allowed for the creation of anterior and posterior flaps (Fig. 1), with the anterior flap secured away from the operative field using 2-0 silk sutures.

Fig. 1
figure 1

Showing the curvilinear vertical flap with its anterior part covering the device without tension

The posterior flap was elevated to expose adequate bone for the receiver stimulator unit, which was secured in a bony well with monocortical holes for stability. Cochlear implantation followed the standard posterior tympanotomy round window cochleostomy approach. After implantation, the periosteal flap was sutured over the unit using 2-0 vicryl (Fig. 2), and the skin was closed with 3-0 monocryl subcuticular sutures. This method ensured complete device coverage and secure positioning within a tightly formed pocket [1].

Fig. 2
figure 2

The periosteal flap sutured over the device. The periosteal and skin sutures are at different planes

This study presents a surgical audit involving 39 patients who underwent cochlear implantation at a distinguished tertiary teaching hospital between July 2020 and September 2021. The cochlear implant surgery utilized a novel periosteal flap technique described by Panda et al. in 2020 (Figs. 1 and 2), henceforth referred to as “Group N.” Among these patients, there were 37 children and 2 adults. For comparison, outcomes related to various flap issues were assessed by evaluating 51 patients (48 children and 3 adults) who underwent cochlear implant surgery between July 2017 and June 2019, utilizing the anteriorly based palva flap; this group is referred to as “Group P.” A comprehensive follow-up period ranging from 2 to 12 months was conducted for all patients.

To evaluate the postoperative outcomes, a standardized scoring system was employed, encompassing parameters such as ease of surgical exposure, surgical maneuverability of the flap, closure convenience after device fixation, immediate postoperative complications (up to 24 h), and delayed complications (up to 30 days). The scoring system assigned a rating from 1 (fair assessment) to 4 (excellent assessment), with the maximum possible score being 18, representing optimal outcomes (Table 1).

Table 1 The scoring sheet for the surgical audit of cases

Comparisons between the two flap techniques were made using the scoring system, encompassing variables like surgical exposure, ease of surgical performance following exposure, incidences of emissary vein injury, ease of wound closure after device fixation, and both immediate and delayed complications (Table 2).

Table 2 Showing the scores obtained for both the palva flap and the novel periosteal flap

In this manner, the study aimed to elucidate the advantages and potential areas of improvement associated with the novel periosteal flap technique, thereby contributing valuable insights to the field of cochlear implantation procedures.

Results

A total of 39 cases, comprising individuals with bilateral profound hearing loss, underwent cochlear implantation utilizing the new periosteal flap technique. Among them, there were 37 children and 2 adults, with the children’s age range spanning from 2 to 6 years and a mean age of 3.5 years. These patients were compared with 51 individuals (48 children and 3 adults) who had undergone cochlear implantation using the anteriorly based palva flap between July 2017 and June 2019.

Table 3 displays the various types of devices used in both cohorts. The scoring system facilitated a comparative evaluation between the two flap techniques, as shown in Table 4. Significant differences were observed between the groups for emissary vein injury (chi-square: 27.960, df 1, p = 0.000) and ease of closure of wound after device fixation (chi-square: 90.000, df 1, p = 0.000). However, the variables of surgical exposure (p = 1), ease of working after exposure (chi-square: 1.564, df 1, p = 0.211), immediate complications within 24 h (chi-square: 0.076, df 1, p = 0.783), and delayed complications (chi-square: 2.373, df 1, p = 0.123) did not exhibit statistically significant differences between the two groups.

Table 3 Comparison of flap scores for the different devices used in our cohort
Table 4 The comparison between the two groups taking into account the various variable in the proposed scoring

Furthermore, a comparison of the total scores between the conventional palva’s flap group and the newer proposed periosteal flap group revealed mean total scores of 13.67 ± 1.669 and 17.90 ± 0.447, respectively. This difference in total scores between the groups was statistically significant (t: − 17.306, df: 59, p = 0.000).

In terms of complications related to the flaps, the novel flap group exhibited no major complications, while three patients in the palva flap group experienced flap complications necessitating surgical intervention. Specifically, two patients in the palva flap group required preoperative repair of flap tears using temporoparietal fascia flap. Nonetheless, the difference in flap-related complications between the groups did not reach statistical significance on the chi-square test (p = 0.289) (Table 5). Additionally, two cases in the palva flap group displayed minor skin discoloration, which resolved over time.

Table 5 Surgical site complication status comparison between flap techniques
Table 6 Chi-square tests

These findings highlight the potential advantages of the novel periosteal flap technique, showcasing improved surgical outcomes with reduced complications compared to the conventional palva flap approach. The novel flap technique demonstrated superior scores in various parameters, signifying enhanced surgical performance and postoperative recovery. The absence of major complications in the novel flap group further reinforces its safety and efficacy, presenting a promising avenue for optimizing cochlear implantation procedures.

Discussion

Cochlear implantation has been a well-established procedure for over four decades, and despite continuous efforts by surgeons to enhance safety, complications continue to occur. Reported frequencies of major complications after cochlear implantation range from 1.08 to 8.2% [8, 9]. Surgeons have introduced various techniques for raising periosteal flaps to minimize procedure time, ensure safety, and provide adequate coverage for the receiver stimulator unit [5,6,7, 11].

Complications related to skin flaps after cochlear implantation are often associated with inflammation and soft tissue infection surrounding the device. Major flap complications require surgical intervention, while minor complications can often resolve spontaneously and be managed conservatively. A well-vascularized and tension-free flap is of paramount importance in avoiding flap-related complications [12, 13].

The design of both the skin flap and periosteal flap plays a crucial role in minimizing postoperative complications. The periosteal flap should have sufficient blood supply, appropriate width to cover the device, and be free of tension. Repeated manipulation to cover the device can lead to devascularization, resulting in flap necrosis and infection [12, 13].

The need for improved flap techniques led to the development of the novel periosteal flap. Prior to its introduction, the palva flap was commonly utilized at our center until May 2019. However, the thinness of the palva flap in very young children posed challenges and often led to flap tears requiring additional vascularized flaps, such as the temporoparietal flap, to achieve adequate device coverage [1].

Building on the success of a previously reported novel periosteal flap technique [1], this study further examined the efficacy of the same flap in an additional 39 patients who underwent cochlear implant surgery over a 1-year period. These patients were compared to a group of patients who had cochlear implantation using the standard palva flap between 2017 and 2019. The comparative analysis revealed a reduced incidence of emissary vein injury and easier wound closure after device fixation in the novel periosteal flap group, which was statistically significant (p = 0.000). Furthermore, the mean total scores were higher in the novel periosteal group, indicating enhanced outcomes.

This novel periosteal flap boasts several advantages over palva flap, including its robust nature and larger anterior flap that extends more posteriorly to cover the implanted device (Fig. 1). The branches of posterior auricular artery, namely, the auricular and occipital branches form the major blood supply for this flap. The closure of the periosteal flap posteriorly is situated at a considerable distance away from the skin incision, reducing edema, dead space, and the risk of vascular compromise (Fig. 2). Additionally, the flap’s easy raising with minimal tension during device coverage and avoidance of the emissary vein further contribute to its potential in reducing flap complications.

One notable advantage of our flap is its ease of raising without tension while covering the device. Additionally, the flap offers another benefit by avoiding the emissary vein, which is not encountered as the incision to raise the flap is situated more anteriorly. In contrast, the palva flap has the potential to injure the emissary vein due to the incision being located over this area.

Conclusion

In conclusion, the surgical audit of 39 cochlear implantation cases utilizing the novel periosteal flap showcases its clear superiority over the palva flap. The new flap is quicker, well-vascularized, and sturdier, ensuring optimal device coverage with minimal complications. Its potential advantages can be further validated at other centers, reinforcing the benefits of this straightforward periosteal flap.
