Case report: a grievous tale of a rare primary thyroid leiomyosarcoma

Abstract

Background

Primary thyroid leiomysosarcoma is a rare and aggressive disease which represents 0.014% of primary thyroid cancers. It confers a diagnostic conundrum, due to difficulty to make a preoperative diagnosis of thyroid leiomyosarcoma and to differentiate it from anaplastic thyroid carcinoma.

Case presentation

We herein report a rare case of primary thyroid leiomyosarcoma. A 48-year-old male presented with history of anterior neck swelling for the past 2 months. Computed tomography (CT) neck showed hypodense nodule at the right thyroid lobe with calcification causing tracheal deviation, with intratracheal extension at 1st and 2nd tracheal rings and presence of lung metastases. The histopathology analysis yield high grade spindle cell neoplasm suggestive of sarcoma. Immunohistochemistry showed that neoplastic spindle cells were positive for smooth muscle actin, vimentin, caldesmon while no reactivity was reported for thyroglobulin, calcitonin, thyroid transcription factor-1, S-100, CD45, CD 5, and cytokeratins. Patient had undergone tracheostomy and chemotherapy but he succumbed to death 1 month after completion of chemotherapy.

Conclusion

Primary thyroid leiomyoarcoma is a very rare and aggressive disease. The treatment ranging from surgery, adjuvant radiotherapy and chemotherapy, with high recurrence rates.

Background

Thyroid can give rise to different types of malignancy, whereby primary cancer is the most common type [1]. World Health Organization (WHO)’s histological classification of thyroid and parathyroid tumors divides smooth muscle tumors into benign (leiomyoma) or malignant (leiomyosarcoma) [2]. Thyroid leiomysosarcoma is very rare and represents 0.014% of primary thyroid cancers. It confers a diagnostic conundrum, due to difficulty to make a preoperative diagnosis of thyroid leiomyosarcoma and differentiate it from anaplastic thyroid carcinoma [3]. The prognosis is poor in spite of aggressive surgery, adjuvant radiotherapy and chemotherapy, with high recurrence rates and an estimated 1-year survival of only 5–10% [4]. Few have reported on this case. In this report, one patient with primary thyroid leiomyosarcoma presented with review of literature.

Case presentation

A 48-year-old male presented with anterior neck swelling for the past 2 months, which rapidly increasing in size for 2 weeks (Fig. 1). He developed obstructive symptoms such as shortness of breath, noisy breathing and reduced effort tolerance. He experienced hoarseness with no aspiration symptoms. There was no symptoms of hyper- or hypothyroidism. He was initially intubated and ventilated for 3 days due to respiratory distress. Endoscopic laryngeal assessment revealed right vocal cord adductor palsy at lateral position. Subsequently, contrast-enhanced computed tomography (CECT) neck and thorax and ultrasound guided tru-cut biopsy of the right thyroid nodule were performed.

Fig. 1
figure 1

Anterior neck swelling, appears to be thyroid origin

CECT showed hypodense nodule at the right thyroid lobe with calcification measuring 7 cm × 4.8 cm × 8.2 cm, causing tracheal deviation, with intratracheal extension at 1st and 2nd tracheal rings and no clear plane with prevertebral muscles (Fig. 2). The scan showed presence of lung metastases.

Fig. 2
figure 2

Axial CT scan showed heterogenous mass with area of calcification arise from right thyroid lobe

The histopathology analysis yield high grade spindle cell neoplasm suggestive of sarcoma (Fig. 3). Immunohistochemistry showed that neoplastic spindle cells were positive for smooth muscle actin (Fig. 4), vimentin, caldesmon (Fig. 5) while no reactivity was reported for thyroglobulin, calcitonin, thyroid transcription factor-1, S-100, CD45, CD 5, and cytokeratins.

Fig. 3
figure 3

Moderately pleomorphic spindle cells arranged in storiform and fascicles with area of necrosis (haematoxylin eosin (H&E) × 20)

Fig. 4
figure 4

Diffuse and strong membranous and cytoplasmic expression for Smooth muscle actin (SMA)× 20

Fig. 5
figure 5

Presence of focal expression of H-caldesmon × 40

Subsequently, he had undergone tracheostomy. Intraoperative findings revealed the tumor arising from the right thyroid lobe, adhered to the anterior wall of the trachea, and infiltrated intraluminally. The mass was firm to hard. He had received palliative chemotherapy Doxorubicin. However, CECT scan post completion of chemotherapy yield devastating advanced stage of thyroid leiomyosarcoma whereby the tumor encased the right common carotid artery with multiple enhancing brain lesion at the right parietal and frontal lobes, likely to be brain metastases. Unfortunately, he succumbed to death 1 month after completion of chemotherapy.

Discussion

Papillary and follicular variants are the most common type of thyroid neoplasms, followed by medullary cancers [2]. Primary leiomyosarcoma (LMS) of the thyroid gland is a very rare tumor which accounts for 0.014%. They usually develop in older people (mean age 66 years) with no gender predisposition [4, 5]. Primary LMS may originate from smooth muscle cells of the capsule vessels. Metaplasia from a previously existing thyroid anaplastic carcinoma should take into consideration as well [2]. The initial symptom of all adult cases in the literature was mainly a rapidly growing mass in the neck, which causes breathing obstruction and dysphagia [3].

Primary LMS has no characteristic imaging features that might be useful for diagnostic purposes [5]. However, in the tumors observed in the ultrasonography (US) had smooth borders or were irregularly hypoechoic without halo, had cystic parts, were solid, and in some cases were calcified masses [3]. In the CTs, the masses involved large necrosis areas, with or without calcification [1, 3]. Ultrasound-guided tru-cut biopsy in our case was able to yield sufficient cells sample for further analysis.

Spindle cell tumor with thymus-like differentiation (SETTLE), anaplastic thyroid carcinoma and medullary thyroid carcinoma are thyroid epithelial tumors that can imitate sarcomas with a spindle cell pattern [5]. Thus, it can be difficult to exclude a diagnosis of undifferentiated thyroid carcinoma. Histologically, these tumors composed of an admixture of spindle cells, pleomorphic giant cells, and epithelioid cells. The percentage and distribution of these cell types varies widely from case to case. Tumors composed predominantly of spindle cells often have a sarcomatoid appearance. The individual neoplastic cells are elongated, with abundant acidophilic fibrillary cytoplasm; the nucleus is generally centrally located [2, 4, 5].

Immunohistochemically, LMS show reactivity for vimentin, smooth muscle actin, muscle-specific actin, smooth muscle myosin, desmin, H-caldesmon, and basal lamina components, including laminin and type IV collagen. H-caldesmon is a muscle marker used to discriminate between smooth muscle cells and myofibroblasts. On immunohistochemistry, positivity for smooth muscle actin, vimentin, desmin, and caldesmon may diagnose thyroid LMS, while these tumour cells show no reactivity to keratin, thyroglobulin, chromogranin, and calcitonin [2, 4, 5].

The dilemma in managing this case in terms of diagnosis and treatment enthralled surgeons. In contrast to thyroid carcinoma, there is no general recommendations regarding therapy and follow-up of LMS. Treatment strategies for LMS ranging from surgery, with or without additional chemotherapy and local radiation to palliative care. In this case, due to advanced LMS, it is not amenable for surgery, thus patient underwent chemotherapy, but the tumor showed poor response to chemotherapy. The general prognosis of thyroid leiomyosarcoma is poor. The disease is mostly fatal and survival rates are reported to be 5–10% in the first year [13]. We have reviewed several articles that mentioned their experiences in managing primary thyroid leiomyosarcoma (Table 1).

Table 1 Summary of 3 reports that discussed the management and outcomes of Primary thyroid leiomyosarcoma

Conclusion

The encounter with primary thyroid leiomyosarcoma is a rare occurrence. It is a fatal disease which possessed a diagnostic conundrum as it may mimics anaplastic thyroid carcinoma. The management ranged from surgery, chemotherapy, and radiotherapy.

Availability of data and materials

All data generated or analysed during this study are included in this published article (and its supplementary information files).

References

  1. Surov A, Gottschling S, Wienke A, Meyer AW, Spielmann P et al (2015) Primary thyroid sarcoma: a systematic review. Anticancer Res 35(10):5185–5191

    Google Scholar

  2. Conzo G, Candela G, Tartaglia E, Gambardella C, Mauriello C et al (2014) Leiomyosarcoma of the thyroid gland: a case report and literature review. Oncol Lett 7(4):1011–1014. https://doi.org/10.3892/ol.2014.1853 Epub 2014 Feb 4. PMID: 24944660; PMCID: PMC3961299

    Article  Google Scholar

  3. Şahin MI, Vural A, Yüce I, Çağlı S, Deniz K et al (2016) Thyroid leiomyosarcoma: presentation of two cases and review of the literature. Braz J Otorhinolaryngol 82(6):715–721. ISSN 1808-8694. https://doi.org/10.1016/j.bjorl.2015.11.020

    Article  Google Scholar

  4. Reddy B, Aggarwal V, Ajmani AK, Sachan S, Khandelwal D (2019) Primary leiomyosarcoma of the thyroid gland - a rare malignancy. Eur Endocrinol 15(1):44–46. https://doi.org/10.17925/EE.2019.15.1.44 Epub 2019 Apr 12. PMID: 31244910; PMCID: PMC6587898

    Article  Google Scholar

  5. Mevio E, Mevio N, Cazzaniga M, Sbrocca M, Migliorini L et al (2015) Leiomyosarcoma of the thyroid gland: a review of the literature and our experience. J Thyroid Cancer 1(1):1–7

    Article  Google Scholar

Download references

Acknowledgements

Not applicable.

Funding

Not applicable.

Author information

Authors and Affiliations

Authors

Contributions

WN made the conception and design of the work and writing. RJ and AA made the acquisition, analysis, and interpretation of data. KA performed the editing of the manuscript. NA performed editing of the manuscript. All authors read and approved the final manuscript.

Corresponding author

Correspondence to Wan Nabila Wan Mansor.

Ethics declarations

Ethics approval and consent to participate

Not applicable.

Consent for publication

Consent for publication was obtained verbally and in written form obtained from the next of kin.

Competing interests

The authors declare that they have no competing interests.

Additional information

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Rights and permissions

Open Access This article is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons licence, and indicate if changes were made. The images or other third party material in this article are included in the article's Creative Commons licence, unless indicated otherwise in a credit line to the material. If material is not included in the article's Creative Commons licence and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this licence, visit http://creativecommons.org/licenses/by/4.0/.

Reprints and Permissions

About this article

Verify currency and authenticity via CrossMark

Cite this article

Wan Mansor, W.N., Abdul Gani, N., Abu Dahari, K.A.S. et al. Case report: a grievous tale of a rare primary thyroid leiomyosarcoma. Egypt J Otolaryngol 39, 4 (2023). https://doi.org/10.1186/s43163-022-00364-1

Download citation

  • Received:

  • Accepted:

  • Published:

  • DOI: https://doi.org/10.1186/s43163-022-00364-1

Keywords

  • Thyroid
  • Leiomyosarcoma
  • Aggressive
